G058-116-1/CC32 - Oil cooler, version CC32

Réf: G058-116-1/CC32

G058-116-1/CC32 Echangeur d'huile, version CC32
search
  • G058-116-1/CC32 Echangeur d'huile, version CC32

This heat exchanger has been initially designed to cool marine gearboxes, meaning it is highly resistant to pressure and completely compatible with sea water. Usually installed on inverters mounted with engines up to 190hp.



MOTA design ensures that this cooler will not experience thermal expansion stress providing extended longevity.

Its characteristic and material choices also allow it to be an excellent choice for all other types of applications:

  • engine oil cooling
  • diesel fuel cooling
  • hydraulic oil cooling or heating

Installation is very quick and easy provided by simple hose connections on the cold side and standard threaded connections on the hot side.

All heat exchangers provided by MOTA deliver our highest standard heat rejection: high density tubestack allows a very compact heat exchanger with high performance.

Data sheet

Cold side anodes
No anode
Hot side connexion
3/8\" Rp
Cold side connexion
Ø32mm
Tubes diameter (mm)
6
Tubestack diameter (Ømm)
58
Range
G range
Tubestack length (mm)
116
Covers material (water cover)
Plastic PA6.6
Tubes material
Cu
Housing material
Extruded aluminium
Number of passes (colde side)
1
Number of tubes
49
Cold side flow range ( L/min )
45 - 60
60 - 75
75 - 100
100 - 150
Type of cooler
Heat exchangers (water / oil / fuel)
Connexion type (cold side)
Hose
Liquid type (cold side)
Untreated water (sea type)
Sector of activity
Industrial application
Marine
Stationary engines
Transmissions
Vehicles
Advantages
Anti corrosion
