MOTA Reinforced charge air cooler Ø97mm, high water flow version
Réf: CAC097-261-2/CN-BR
search
This new charge air cooler (intercooler) has been designed to be reliable, performant and easy to install on any type of application.
- marine engine
- industrial engine (gen-sets, cogeneration, fire pumps, ...)
- test bench
- compressor
- other application
It is dismountable to allow for easy cleaning and maintenance. The only parts to be changed are the o-rings!
- Hot side connexion
- Ø68mm
- Cold side connexion
- Tubestack diameter (Ømm)
- 97
- Range
- Charge air cooler (interncooler)
- Covers material (water cover)
- Brass
- Tubes material
- CuNi
- Housing material
- Painted aluminium
- Number of passes (colde side)
- 2
- Cold side flow range ( L/min )
- 45 - 60
60 - 75
75 - 100
100 - 150
- Type of cooler
- Charge air cooler (interncooler)
- Sector of activity
- Industrial application
Marine
Stationary engines
Transmissions
Vehicles
- Advantages
- Anti corrosion
Easy maintenance
Sector of activity
Advantages
